Engineered for high-pressure cementing and fracturing operations, ensuring reliable flow control in demanding oilfield environments.
Features a compact structure ideal for high-pressure manifolds, ensuring rapid opening and easy operation.
Designed for low torque operation, allowing for easy opening and closing even under pressures up to 10,000 PSI.
Utilizes a high-precision metal-to-metal seal between the side segments and cylinder plug for stable, reliable performance.
Constructed from high-strength forged alloy steel to withstand harsh working mediums, including oil, gas, and mud.
Equipped with FIG 1502 union end connections for seamless integration into existing fracturing and cementing flowlines.
Simplified design allows for straightforward field maintenance, prolonging service life and reducing downtime.
Working Pressure: 42MPa - 140MPa (5000-15000 PSI)
Nominal Bore Size: 1-inch to 3-inch options available
Connection Type: FIG 1502 Wing Union Inlet and Outlet
Material Class: AA, BB, CC, DD, EE, FF, HH
Working Temperature: -29°C to 121°C (Class PU)
Applicable Medium: Oil, natural gas, mud, and fluids containing H2S or CO2
